Giant 2027 Propel Advanced Pro 0 AXS
Bikes available to order from Australia. Please contact store for availability and ordering on 04 589 2822 or support@cyclescience.co.nz
Hang with the fast group, go for the sprint, cheat the wind on a solo ride. The new Propel Advanced Pro is now lighter, smoother and more efficient, delivering higher speeds to help you maximize every effort.
Instant Speed
In the moments when explosive speed matters most—launching an attack, chasing a break, or sprinting for the finish line—the new Propel Advanced Pro is quicker and more dynamic than ever. The frameset is lighter than the previous generation with greater torsional stiffness and pedaling stiffness—so you feel instantaneous reaction when you make your move.
Sustained Speed
A reengineered frameset and integrated components combine for a smoother ride when you’re rolling in the group or piling up training miles. The Vector seatpost offers greater compliance compared to the previous generation, while the fork and integrated cockpit absorb bumps and vibrations up front. And additional tire clearance allows for high-volume tires up to 32mm, further smoothing out the ride to help you maintain higher speeds with less fatigue.
Top-End Speed
The frameset, cockpit, wheels and tires form a unified system that lowers total resistance when you’re pushing high speeds. The AeroSystem frame and integrated cockpit minimize drag, while the aero WheelSystem and tires reduce rolling resistance. That means more speed for taking pulls, rolling off the front, or driving the pace across flats and over climbs.
Giant 2027 Propel Advanced Pro 0 AXS
Frame
Size: XS, S, M, ML, L, XL
Colour: Obsidian Pulse
Frame: Advanced-grade Composite, 12x142mm thru-axle, disc
Fork: Advanced SL-grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc
Shock:
Drivetrain
Crankset: SRAM Force E1 DUB, 35/48 with power meter XS:165mm, S:165mm, M:170mm, M/L:170mm, L:172.5mm, XL:172.5mm
Pedals:
Chain: SRAM Force E1
Bottom Bracket: SRAM, press fit
Rear Derailleur: SRAM Force AXS E1
Front Derailleur: SRAM Force AXS E1
Shifter: SRAM Force AXS E1
Freewheel/Cassette: SRAM Force, 12-speed, 10x33
Braking System
Brakes: SRAM Force E1 hydraulic, SRAM PaceLine X rotors [F]160mm, [R]140mm
Brake Levers: SRAM Force AXS E1
Wheels
Tyres: CADEX Aero, tubeless, 700x28c (28mm), folding
Wheels/Rims: Giant SLR 0 50 Carbon WheelSystem, [F]50mm, [R]50mm
Hubs: [F] Giant Aero Hub, CenterLock [R] Giant Aero Hub, 40T ratchet driver, CenterLock 12mm thru-axle
Other
Handlebar: Giant Contact SLR 0 Aero Integrated XS:380/360mm, S:380/360mm, M:400/370mm, M/L:400/370mm, L:420/390mm, XL:420/390mm
Stem: Giant Contact SLR 0 Aero Integrated XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm
Seat Post: Giant Vector, composite, -5/+15mm offset
Saddle: Giant Fleet SL
Giant 2027 Propel Advanced Pro 0 AXS
-
- XS
-
157 cm
169 cm
-
- S
-
165 cm 175 cm
-
- M
-
171 cm 181 cm
-
- M/L
-
177 cm 187 cm
-
- L
-
183 cm 193 cm
-
- XL
-
189 cm 199 cm
| XS | S | M | M/L | L | XL | |
|---|---|---|---|---|---|---|
| A Seat Tube Length (mm) | 484 | 505 | 528.5 | 554 | 576 | 595 |
| B Seat Tube Angle | 74.5° | 74.0° | 73.5° | 73.0° | 73.0° | 72.5° |
| C Top Tube Length (mm) | 520 | 535 | 550 | 565 | 580 | 600 |
| D Head Tube Length (mm) | 115 | 127 | 145 | 165 | 185 | 200 |
| E Head Tube Angle | 71.5° | 72.5° | 73.0° | 73.0° | 73.0° | 73.0° |
| F Fork Rake (mm) | 45 | 45 | 45 | 45 | 45 | 45 |
| G Trail (mm) | 67.8 | 61.4 | 58.3 | 58.3 | 58.3 | 58.3 |
| H Wheelbase (mm) | 971 | 973 | 980 | 990 | 1006 | 1020 |
| I Chain Stay Length (mm) | 405 | 405 | 405 | 405 | 405 | 405 |
| J Bottom Bracket Drop (mm) | 72 | 72 | 69.5 | 69.5 | 67 | 67 |
| K Stack (mm) | 515 | 530 | 546 | 565 | 582 | 596 |
| L Reach (mm) | 377 | 383 | 388 | 392 | 402 | 412 |
| M Stand Over Height (mm) | 746 | 764 | 787 | 808 | 832 | 847 |
| N Handlebar Width (mm) | 380 | 380 | 400 | 400 | 420 | 420 |
| O Stem Length (mm) | 80 | 90 | 100 | 110 | 110 | 120 |
| P Crank Length (mm) | 165 | 165 | 170 | 170 | 172.5 | 172.5 |
| Q Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
