Marin 2023 Rift Zone 1

Please manually select shipping rates at checkout

Finance Plans Available

Description
Specifications
Geometry

Description

Marin 2023 Rift Zone 1

Feel the Rifty Love! Our take on the ultimate do-it-all trail bike, the Marin Rift Zone is made to party, whatever your jam might be. Your ideal partner for everything from all-day epics, to local shred laps to big mountain adventures, the Rifty is Made For Fun.

The Rift Zone 29 brings together trail-taming 29" wheels, 130mm of rear travel, a lightweight aluminum frame and our super-plush MultiTrac suspension platform for endless good times on the trails.

The Marin Rift Zone 29 1 is your gateway to the Rifty family, made to push the limits of your riding but not your bank balance. It's built with super reliable X-Fusion suspension, grippy Vee Crown Gem tires, plenty of Shimano and a hand-picked selection of our favorite Marin components.

Specifications

Marin 2023 Rift Zone 1

Frame

Colour: Charcoal Black
Frame: All New Series 3 6061 Aluminum Frame, 29” Wheels, 125mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148x12), 73mm Threaded BB w/ ISCG05 Tabs
Fork: X-Fusion Slide Boost RC, 29", 140mm Travel, Compression and Rebound Adjustment, 44mm Offset
Shock: X-Fusion O2 Pro R, Custom Tune, 210x50mm, M8x25mm Hardware Top and Bottom

Drivetrain

Crankset: Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing
Chain: KMC X-11 Silver and Black
Bottom Bracket: External Sealed Cartridge Bearing
Rear Derailleur: Shimano Deore, 11-Speed, SGS
Front Derailleur:
Derailleur Shifter: Shimano Deore, 11-Speed, SL-5100R
Freewheel/Cassette: Sunrace, 11-Speed, 11-51T, ED Black

Braking System

Brakes: [F] and [R] Shimano BR-MT200 Hydraulic Disc, 180mm Rotor
Brake Levers: Shimano BL-MT201

Wheels

Tyres: [F] and [R] Vee Tire Crown Gem 29x2.35", Dual Control Compound, Tubeless Ready
Wheels/Rims: [F] and [R] Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Hubs: [F] Shimano HF-MT400B, 110x15mm, Centerlock [R] Shimano HB-MT200B, 141 QR, Centerlock, Standard Freehub Body

Other

Handlebar: Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Stem: Marin 3D Forged Alloy, 35mm
Saddle: Marin Speed Concept
Seat Post: Marin Alloy, 30.9mm

Geometry

Marin 2025 Rift Zone 1

	S	M	L	XL
STACK	623.6	628.2	637.3	641.8
REACH	435	460	485	515
HEADTUBE ANGLE	65.5°	65.5°	65.5°	65.5°
HEADTUBE LENGTH	110	115	125	130
SEATTUBE ANGLE	77°	77°	77°	77°
SEATTUBE LENGTH	390	400	425	430
TOPTUBE EFFECTIVE	579	605	632.1	663.2
BB HEIGHT	343	343	343	343
BB DROP	35	35	35	35
CHAINSTAY	430	430	430	430
WHEELBASE	1170	1205.1	1234.4	1266.3
STANDOVER HEIGHT	690.2	691.2	701.7	700.5
FORK OFFSET	44	44	44	44

*Please note that our specifications may be impacted by running substitution changes, we highly recommend confirming the specifications of our products at the time of sale. *Recommended Retail Prices are subject to change without notice and may vary from store to store depending on freighting and assembly costs. Please read our Terms & Conditions

*Giant & Liv Bicycles are available for purchase online, but due to warranty regulations, must be shipped to qualified Giant dealers, as bicycles must be assembled by a qualified bike mechanic in an approved store - This is an international policy and usually will require an additional fee to build the bike. This will be confirmed by one of our online staff after purchase of the bike.

*Specialized Bicycles are available for home delivery nation wide.

*AMFLOW Bicycles are available for purchase online, but MUST be collected from the store.

*TREK Bicycles are available for purchase online, but MUST be collected from the store.
