Merida 2026 Scultura Rim 100
A high-performance road bike at a price that's hard to beat. With a quality, lightweight aluminium frame, carbon fibre fork and durable groupset from Shimano, this is a machine that'll let you attack the open road without assaulting your wallet.
--
Let the road open up in front of you. The SCULTURA RIM 100 takes everything we know about creating lightweight aluminium frame design and combines it with our unparalleled road racing heritage to deliver a high-value, high-performance road bike. With Shimano's durable and swift shifting CUES 2x9-speed drivetrain and our specially selected finishing kit, this is a bike that will give miles of service and pleasure, wherever it may take you.
The SCULTURA range has always stood for lightweight, road racing performance with a heritage that can be matched by few, but our SCULTURA RIM bikes offer the benefit of our years of road bike knowledge at a price point that's available to everyone. At MERIDA, we know how to create quality, long-lasting aluminium frames, so it's fitting we choose this material for our SCULTURA road bikes that give top flight performance at an accessible price, sitting alongside our top-end carbon offerings. With geometry that's precise enough for seasoned riders yet welcoming to new recruits to the fast-paced world of drop bar bikes, these are machines that let the road open up in front of you.
- Lightweight rim brake-only aluminium frame
- Carbon fibre CF2 fork for comfort and control
- Shimano CUES 2x9-speed drivetrain
- Lee-Chi brakes for powerful performance
- MERIDA COMP SL wheelset
- Fast rolling Maxxis Pursuer 25 mm tyres
Merida 2026 Scultura Rim 100
Frame
Size: XS, S, SM, ML, L, XL
Colour: Blue/Green Clear Coat(Silver) and Metallic Black(Gunmetal Grey)
Frame: SCULTURA LITE BSA, MAT aluminium, 700x25C max. WHS, 100x9/ 135x9 AST, BSA BBR,
Fork: SCULTURA RIM CF2, 700x25C max. WHS
Shock: ,
Drivetrain
Crankset: Prowheel, 50-34t
Pedals:
Chain: KMC M700,
Bottom Bracket: FSA TH-7420ST, Cartridge Bearing,
Rear Derailleur: Shimano CUES, SGS 9S
Front Derailleur: Shimano CUES U6030,
Shifter: [F] Shimano CUES U3030-L, [R] Shimano CUES U3030-9R,
Freewheel/Cassette: SunRace U98, 11-36, 9sp,
Braking System
Brakes: [F] [R] Lee Chi ROAD Dual Pivot,
Brake Levers:
Wheels
Tyres: [F] and [R] Maxxis Pursuer, 700x25C, fold,
Wheels/Rims: MERIDA COMP SL, 17 IWR, 20 HRI, MAT aluminium, not Tubeless ready,
Hubs: [F] Road seal bearing, 100x9 WHF, 24 SPH, [R] Road seal bearing, 130x9 WHR, 28 SPH,
Other
Handlebar: MERIDA EXPERT SL, MAT aluminium, 380mm(XXS), 400mm (XS-S), 420mm (S/M-M/L), 440mm (L-XL),
Stem: MERIDA COMP CC, MAT aluminium, 31.8 DSH, -7 ASD
Seat Post: MERIDA COMP CC, 27.2 DSP, 0 SSB, MAT aluminium
Saddle: MERIDA COMP SL, V-mount
Merida 2026 Scultura Rim 100
| Frame Size | 4XS | 3XS | XXS | XS | S | S/M | M/L | L | XL |
| Tyre Sizes | 28" | 28" | 28" | 28" | 28" | 28" | 28" | 28" | 28" |
| ST seat tube [mm] | 380 | 410 | 440 | 470 | 500 | 520 | 540 | 560 | 590 |
| TT top tube [mm] | 490 | 500 | 515 | 520 | 530 | 545 | 560 | 575 | 590 |
| CS chain stay length [mm] | 408 | 408 | 408 | 408 | 408 | 408 | 408 | 408 | 408 |
| HTA head tube angle [°] | 70 | 70.5 | 71 | 71 | 72 | 73 | 73 | 73 | 73.5 |
| STA seat tube angle [°] | 75 | 75 | 75 | 74.5 | 74 | 74 | 73.5 | 73 | 73 |
| BD bottom bracket drop [mm] | 70 | 70 | 66 | 66 | 66 | 66 | 66 | 66 | 66 |
| HT head tube [mm] | 95 | 100 | 120 | 130 | 140 | 150 | 170 | 190 | 215 |
| FL fork length [mm] | 375 | 375 | 375 | 375 | 375 | 375 | 375 | 375 | 375 |
| R reach [mm] | 358 | 366 | 376 | 373 | 375 | 386 | 390 | 394 | 401 |
| S stack [mm] | 492 | 499 | 519 | 529 | 542 | 555 | 574 | 593 | 619 |
| WB wheel base [mm] | 972 | 979 | 982 | 983 | 979 | 985 | 995 | 1005 | 1014 |
| SH stand over height [mm] | 654 | 669 | 697 | 720 | 744 | 762 | 779 | 798 | 826 |
