Merida 2026 Silex 200
Dream big, without the big budget. The SILEX 200 is the entry to our world of adventure gravel riding, with our high-quality aluminium frame and lightweight carbon fork paired with affordable but durable components, such as a Shimano 1x8-speed ESSA drivetrain and grippy, comfortable 45 mm Maxxis tyres. It’s the perfect weekday companion that turns into a willing partner in crime for big weekend bikepacking adventures.
The SILEX turns any ride into an adventure, whether you’re on a multi-day gravel bikepacking mission or just taking the fun route to work. With multiple test wins, press accolades, industry awards and even a World Championship title under its belt, our SILEX takes the off-road capability of gravel bikes to new heights, thanks to a slacker head angle and boosted tyre clearance of up to 700x45 mm or even 42 mm with fenders. We've combined that confident mountain bike-inspired handling with all-surface versatility so that it is utterly stable when loaded up with luggage but still fast and fun when you put the hammer down. With carbon and aluminium frame options, there's a SILEX to suit every budget, but they all share the multiple mounting points for fork cages, water bottles and accessories and other features that make this drop-bar do-everything machine so versatile. We’ve added our sleek WIRE PORT cable routing for improved looks – and fewer cables to catch on with a handlebar bag – and the carbon fibre fork used on all models now has more cargo mounts plus internal routing for a dynamo hub. With the ability to use 1x or 2x drivetrains, you can pick your gearing to suit the task at hand or your own personal preference, opening up a world of opportunity for you and your SILEX.
- Award winning aluminium frame with dropped chainstay for 700x45 mm clearance
- Multiple mounting points for cages, bags and fenders
- WIRE PORT internal cable routing for clean looks and scuff free bag fitting
- Carbon fork with cargo mounting points and routing for dynamo hub
- Relaxed head angle and MTB-style geometry for off-road stability
- Shimano ESSA 1x8-speed drivetrain and MERIDA finishing kit
Merida 2026 Silex 200
Frame
Size: XS, SM, MD
Colour: Low Key Green
Frame: SILEX LITE II, MAT aluminium, 700x45C max.WHS, 100x12/142x12 AST, BSA BBR,
Fork: MERIDA SILEX II CF2, Tapered, MAT carbon, 700x47C max. WHS
Shock:
Drivetrain
Crankset: Shimano Essa, 40 ACT; 170 mm-XXS/XS/S/M/L, 175 mm-XL,
Pedals:
Chain: Shimano HG40,
Bottom Bracket: Shimano UN101,
Rear Derailleur: Shimano ESSA, RD-U2000
Front Derailleur:
Derailleur Shifter: Shimano Essa
Freewheel/Cassette: Shimano Essa HG 300, 11-45, 8sp,
Braking System
Brakes: Shimano Essa, Mechanical disc
Brake Levers:
Wheels
Tyres: [F] and [R] Maxxis Rambler, 700x45C, fold, TR, EXO,
Wheels/Rims: MERIDA COMP SL II, 23 IWR, 24 HRI, MAT aluminium, Tubeless ready (tubeless tape and valves not included),
Hubs: [F] [R]
Other
Handlebar: MERIDA EXPERT GRII, MAT aluminium, 400mm (XXS-XS-S), 420mm (M), 440mm (L-XL),
Stem: MERIDA COMP CC, MAT aluminium, 31.8 DSH, -7 ASD; 80 mm all sizes
Seat Post: MERIDA COMP CC, 27.2 DSP, 0 SSB, MAT aluminium
Saddle: MERIDA COMP SL, 25% recycled material, V-mount,
Merida 2026 Silex 200
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| ST Seat Tube (mm) | 460 | 490 | 520 | 550 |
| TT Top Tube (mm) | 550 | 565 | 580 | 600 |
| CS Chain Stay Length (mm) | 430 | 430 | 430 | 430 |
| HTA Head Tube Angle (°) | 69.5 | 69.5 | 69.5 | 69.5 |
| STA Seat Tube Angle (°) | 74.5 | 74.5 | 74.5 | 74.5 |
| HT Head Tube (mm) | 130 | 150 | 170 | 190 |
| R Reach (mm) | 392 | 402 | 412 | 426 |
| S Stack (mm) | 570 | 588 | 607 | 626 |
| WB Wheel Base (mm) | 1048 | 1065 | 1082 | 1104 |
