Scott 2027 Spark DC 20
Please contact store for availability or to PRE-ORDER on 04 589 2822 or support@cyclescience.co.nz
The SCOTT Spark DC 20 is built for riders who want more from every ride. Grounded in our world-class racing pedigree, it brings together cross-country speed and downhill attitude in a single, capable package—engineered for deep mountain missions without compromise.
Every detail is considered to deliver efficiency, stability, and playfulness in equal measure. A low center of mass keeps the ride balanced and controlled through flow trails and jump lines, working through the 140mm front and 135mm rear travel with confidence. The lightweight next-generation HMF carbon frame floats on the climbs and accelerates decisively out of corners and onto open singletrack—a balance of performance and capability refined throughout the Spark legacy.
Keeping your wheels planted—unless that's not your goal—are the ultralight Fox 36SL fork and Float Factory shock, both with a custom tune built for a plush, responsive feel that makes every trail genuinely enjoyable. From short rides and feature sessions to full weekend epics, the suspension is engineered to elevate trail riding across whatever you have planned.
The component spec makes it a high-value package without compromise. Shimano XT Di2 wireless drivetrain and Syncros Silverton AL2 alloy wheels deliver reliable, precise performance across every condition. Integrated frame storage keeps your Save The Day kit and essentials close, and generous bikepacking compatibility means the bike is just as ready for multi-day escapes as it is for your local riding.
Performance also extends to practicality. Improved serviceability and tunability make it straightforward to customize your setup and keep the bike riding exactly how you like it—so you spend less time in the workshop and more time on the trail.
Scott 2027 Spark DC 20
Frame
Size: S,M, L and XL
Colour: Lemon Yellow
Frame: Spark DC HMF Carbon Gen5, Adjustable Head angle and Fork lock, Syncros Cable Integration System Gen2, BSA BB, UDH Interface, 12x148mm with 55mm Chainline
Fork: Fox 36SL Factory Grip SL, Kashima, 3P, Kabolt 15x110mm axle, tapered Steerer, Reb. Adj, Lockout
Shock: Fox Float Factory Traction Control EVOL, Kashima, SCOTT custom w. travel, geo adj., 3P: Lockout-Traction Control-Descend, Low Speed & Reb. Adj., Bearing Hardware 20x8mm, 210X50mm
Drivetrain
Crankset: Shimano XT FC-M8200, 32T
Pedals:
Chain: Shimano CN-M6100
Bottom Bracket: Shimano BB-MT501 BSA
Rear Derailleur: Shimano XT Di2 RD-M8250 12-speed, Wireless Electronic Shift System
Front Derailleur:
Derailleur Shifter: Shimano Deore Di2 SW-M6250
Freewheel/Cassette: Shimano Deore CS-M7200, 10-51T
Braking System
Brakes: Shimano Deore BR-M6220 4-Piston
Brake Levers:
Wheels
Tyres: [F] Maxxis Forekaster 29x2.4", 120TPI Foldable, 3C Maxx Terra, Tubeless Ready, EXO [R] Maxxis Recon 29x2.4", 120TPI Foldable, 3C Maxx Terra, Tubeless Ready, EXO
Wheels/Rims: Syncros Silverton AL2, CL, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready, 28H, Micro Spline
Hubs: [F] [R]
Other
Handlebar: Syncros HB-M200-AL1, Alloy 7075, 760mm, 31.8mm, 7°, 20mm rise, Syncros lock-on grips
Stem: Syncros DC ST-M200-AL2, 0°, 31.6mm
Seat Post: Syncros Dropper Post SP-M301-AL2, +RAD 2.0 drop adjust, 31.6mm
Saddle: Syncros Tofino R 2.0, CrMo Rails
Scott 2027 Spark DC 20
| S | M | L | XL | |
|---|---|---|---|---|
|
A head tube angle |
||||
|
B head tube length |
||||
|
C top tube horizontal |
||||
|
D standover height |
||||
|
E BB offset |
||||
|
F BB height |
||||
|
G wheel base |
||||
|
H BB center to toptube center |
||||
|
I BB center to top of seattube |
||||
|
J seat angle |
||||
|
K chainstay |
||||
|
L reach |
||||
|
M stack |
||||
|
N stem length |
||||
|
O trail |
||||
|
P fork length |
||||
|
Q Maximum Seatpost Insertion |
||||
|
R Handlebar Width |
||||
|
U Crankarm Length |
||||
|
W Seat post drop |
