Trek 2027 EX 5 Gen 7
The Fuel EX 5 is an aluminium trail bike built for total versatility wherever you ride. It comes with a RockShox Recon Silver fork and RockShox Deluxe Select suspension, tubeless-ready wheels, a 12-speed Shimano Deore drivetrain, and a TranzX dropper post, so you're ready for anything.
Trek 2027 EX 5 Gen 7
Frame
Size: S, M, L, XL
Colour:
Frame: Alpha NEXT Platinum aluminium, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm
Fork: RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 150 mm travel
Shock: RockShox Deluxe Select, 205mm x 60mm
Drivetrain
Crankset: Shimano MT520 Deore, 30T ring, 55mm chainline, 165mm length
Pedals:
Chain: Shimano Deore M6100, 12-speed
Bottom Bracket: Shimano BB-MT501 BSA
Rear Derailleur: Shimano Deore M6200, long cage
Front Derailleur:
Derailleur Shifter: Shimano Deore M6200
Freewheel/Cassette: Shimano M6200, 10-51, 12-speed
Braking System
Brakes: Shimano hydraulic disc, MT201 lever, MT200 calliper
Brake Levers:
Wheels
Tyres: Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 29x2.40"
Wheels/Rims: Bontrager Line TLR 30, Tubeless-Ready,
Hubs: [F] Shimano TC500 alloy, CentreLock, 110x15 mm thru axle [R] Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Other
Handlebar: Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm widt
Stem: Bontrager Comp, 31.8 mm, 7-degree, 35 mm length
Seat Post: S: TranzX JD-YSI34, 150 mm travel, internal routing, 34.9 mm M, L, XL: TranzX JD-YSI34, 170mm travel, internal routing, 34.9 mm
Saddle: Bontrager Verse Short, stainless steel rails
Trek 2027 Fuel EX 5 Gen 7
Sizing
| Size | Rider Height | Inseam |
|---|---|---|
| S |
155 - 165 cm 5'1" - 5'5" |
74 - 78 cm 29" - 31" |
| M |
165 - 177 cm 5'5" - 5'10" |
79 - 83 cm 31" - 33" |
| L |
177 - 188 cm 5'10" - 6'2" |
84 - 89 cm 33" - 35" |
| XL |
188 - 195 cm 6'2" - 6'5" |
89 - 91 cm 35" - 36" |
All measurements provided in cm unless otherwise stated.
| Frame size number | Frame size letter | Wheel size | A — Seat tube | B — Seat tube angle | Effective seat tube angle | C — Head tube length | D — Head angle | E — Effective top tube | F — Bottom bracket height | G — Bottom bracket drop | H — Chainstay length | I — Offset | J — Trail | K — Wheelbase | L — Standover | M — Frame reach | N — Frame stack | Front centre |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 15.5" | S | 29"/27.5" | 37.0 | 72.7° | 78.7° | 9.5 | 64.6° | 54.8 | 34.0 | 3.4 | 43.7 | 4.4 | 12.9 | 118.7 | 74.8 | 43.1 | 61.0 | 75.4 |
| 17.5" | M | 29" | 40.0 | 72.6° | 78.3° | 11.0 | 64.5° | 58.3 | 33.9 | 3.5 | 43.7 | 4.4 | 12.9 | 122.5 | 74.4 | 46.0 | 62.4 | 79.1 |
| 19.5" | L | 29" | 42.0 | 72.6° | 77.4° | 12.5 | 64.5° | 61.7 | 33.9 | 3.5 | 44.2 | 4.4 | 12.9 | 126.2 | 74.7 | 48.5 | 63.8 | 82.2 |
| 21.5" | XL | 29" | 45.5 | 72.6° | 76.9° | 14.0 | 64.5° | 65.1 | 33.9 | 3.5 | 44.7 | 4.4 | 12.9 | 129.8 | 75.8 | 51.0 | 65.1 | 85.4 |
